Belzona 2111
D&A Hi-Build Elastomer
A flexible abrasion resistant polyurethane elastomer for the repair, rebuilding and coating of rubber components and metal surfaces.
A 2-part polyurethane resin designed for the repair, rebuilding and coating of rubber and metal components.
- SeriesBelzona 2000 Series
- Documents5
Overview of Belzona 2111
A 2-part polyurethane resin designed for the repair, rebuilding and coating of rubber and metal components. This flexible rubber repair material is appropriate for applications where high build, durability, elasticity, high abrasion and tear resistance are required. This material is easy to mix and apply without the need for specialist tools and it cures at room temperature eliminating the need for hot work.
Key Benefits
Outstanding protection against wear, impact and abrasion
Cures at room temperature with no hot work or vulcanisation
Bonds to natural rubber, nitrile, neoprene, SBR, polyurethane, PVC, steel, copper and concrete
High tensile and tear strength for demanding mechanical environments
Outstanding resistance to a wide range of chemicals
Small or large areas treated in one operation with no joint lines
Application Areas
What this product handles, grouped by equipment area — each links to the full application.
Solids Handling Machinery
3 applications- Pump impeller & casing wear protectionDurable impact and wear protection on pumps volutes and impellersLearn more
- Abrasion-resistant rubber liningsSurfacing rubber and metal components to provide durable abrasion resistanceLearn more
- Conveyor belt repairOn site repair and encapsulation of clip joints on conveyor beltsLearn more
Technical Data
Mechanical Properties (ASTM D412 Die C)
- Tensile Strength (24 hr cure)
- 1970 psi / 13.6 MPa
- Tensile Strength (7 day cure)
- 2355 psi / 16.2 MPa
- Tensile Modulus (24 hr cure)
- 180 psi / 1.3 MPa
- Tensile Modulus (7 day cure)
- 335 psi / 2.3 MPa
- Elongation (24 hr cure)
- 450-550%
- Elongation (7 day cure)
- 350-450%
- Shore A Hardness (24 hr cure)
- 91
- Shore A Hardness (7 day cure)
- 93
- Tear Strength (ASTM D624)
- 370 pli / 6600 kg/m
- Compression Set (BS 903 part A6)
- 22% (30 min recovery)
Adhesion (ASTM D429 90° Peel, Grit Blasted Mild Steel)
- Peak Adhesion
- 172 pli / 3065 kg/m (Tape Failure)
Abrasion (Taber ASTM D4060, H18, 1kg load)
- Dry
- 41 mm³ loss per 1000 cycles (7 day cure)
- Wet
- 16 mm³ loss per 1000 cycles (7 day cure)
Electrical Properties
- Dielectric Strength (ASTM D149)
- 7.1 kV/mm (177 V/mil) at 500 V/s
- Dielectric Constant (ASTM D150)
- 5.02 at 1.0 V and 100 Hz
- Volume Resistivity (ASTM D257)
- 2.30 × 10¹² Ωcm at 500 V DC
Gas Permeability
- Carbon Dioxide (ASTM D1434-82, 2.6mm thickness, 23°C)
- 39 ml/m².atm.day
Working Life
- At 68°F (20°C)
- 12 minutes (gel time approximately 4 minutes)
Curing Time
Cure times will vary depending on ambient conditions; consult the Belzona IFU for specific details. Hardness develops as follows:
At 68°F (20°C)
Lower temperatures will extend cure times. Working life and cure time vary significantly with temperature.
- 24 hour cure
- Shore A 91
- 7 day cure
- Shore A 93 (full cure)
Service Temperature Limits
Note: Surface conditioning with Belzona 2911 (Elastomer QD Conditioner) or Belzona 2921 (Elastomer GP Conditioner) is required for proper adhesion to most substrates.
- Dry Service Range
- -40°F to 194°F (-40°C to 90°C)
- Wet/Immersed Maximum
- 104°F (40°C)
Mixing & Application
